3 Ways To Connect Cisco Jabber And Microsoft Teams

Connect Cisco Jabber and Microsoft Teams

When you’ve got legacy users who need to communicate with new remote users, it’s time to connect Cisco Jabber and Microsoft Teams.

You might have been a Cisco house since the introduction of your PBX or telepresence solution many moons ago. But, upon moving to remote working, you’ve now got pockets of Microsoft Teams users who need to chat with your Jabber users.

It might also be the case that you use Jabber and are moving to Webex in the near future. But your suppliers, contractors, and clients all use Microsoft Teams.

Instead of switching between apps or resorting to email to accommodate them, wouldn’t it be great if you could stay in Jabber and chat with those Microsoft users?

In this post, we cover all the ways you can connect Jabber and Microsoft Teams:

  1. Cisco Jabber calling integration for Microsoft Teams
  2. Microsoft Teams Cisco Call Manager integration
  3. Cisco Jabber federation with Microsoft Teams

1 – Cisco Jabber calling integration for Microsoft Teams

Cisco Jabber encompasses all forms of unified communications into a single app. Jabber has voice, video, messaging, and conferencing capabilities. People across the organization can collaborate using this app on their device of choice.

Businesses that have already invested in Cisco Unified Communications (CUC) want to maximize their investment for the future.

Jabber offers the advantage of using CUC infrastructure. It can seamlessly move from a chat, to a call to external numbers or SIP addresses – thus providing business-quality video and voice.

Cisco Jabber app is straightforward and intuitive, whether you are using it from your desktop or phone.

Organizations with internal groups, or external vendors using Microsoft Teams can easily integrate Cisco Jabber without having to overhaul the complete system.

The Jabber app can be used on your desktop, android device, iPhone, and iPad. Starting a call is easy from the chat window for all of the devices. Additionally, you can assign speed dials and use the keypad to call people on a desktop.

Using the Jabber app within Microsoft Teams

Microsoft Teams is a chat-centered workspace in Microsoft 365. The Teams client can be  installed on any device and the functionality of Jabber on Teams remains almost the same across all devices.

Initiating Cisco Jabber calls from Microsoft Teams chat

The Cisco Jabber application needs to be installed in the desktop/ mobile device on which the Teams application is running.

Video calls using the Cisco Jabber app inside Microsoft Teams

Jabber only works with Microsoft Teams’ cloud-based solution and doesn’t have an on-premises offering.

How to configure Cisco Jabber for Microsoft Teams

The Cisco Jabber app needs to be allowed from the Microsoft Teams Admin Center. Users can then install Jabber from the “Apps” section of their Teams client.

As an Administrator:

  • Log in to Microsoft Teams Admin Center
Log in to Microsoft Teams Admin Center
  • Click on Teams Apps > Manage Apps, from the menu on the left
Connect Cisco Jabber and Microsoft Teams
  • Search for Jabber in the search box. Click on the app name in the search results
  • Toggle on the app status to allowed
Add Cisco Jabber to Microsoft Teams
  • From the menu on the left, go to Teams apps > Permission policies
Microsoft Teams permission policies
  • Select the policy for your organization, and make sure Third Party apps are set to Allow all apps
Allow Third Party apps Microsoft Teams
  • From the menu on the left, select Teams apps > Setup policies
  • Select the policy for your organization
  • Click Add > Add Apps, then search for Jabber and click Add
  • Click Add at the bottom of the screen to confirm
  • Click Save

If you’re an end user, here’s how you install the Jabber app on your Teams client:

  • After launching Teams on your desktop/ laptop, go to Apps on the left panel of the Teams window.
  • Search for Jabber
Connect Cisco Jabber and Microsoft Teams
  • Click on “Jabber” and then hit “Add”
Connect Cisco Jabber and Microsoft Teams
  • After installation the Jabber app will show up on the left panel of the Teams window

Cisco Jabber features in Microsoft Teams

With the Cisco Jabber app, you can dial an extension via the keypad, search your contacts, and also save your personal speed-dial list.

Cisco Jabber features in Microsoft Teams
  • You can search for a contact from the search box listed under “Make a call”
Make a Cisco Jabber call from Microsoft Teams
  • You can also use the dial-pad to make calls if you know the number/ extension
Dialpad Microsoft Teams
  • Speed-dials can be configured by clicking on the “Add a speed dial” button on the upper right-hand corner of the screen
Add speed dial Microsoft Teams
  • A pop-up window will appear where you can enter a name and a number that you would like to save for the speed dial
Add speed dial Microsoft Teams
  • Click Add to save it to your speed dials list
Add Cisco Jabber speed dials to Microsoft Teams

 2 – Microsoft Teams Cisco Call Manager integration

Integration between Cisco Call Manager and Microsoft Teams can help you get the best of both worlds. Especially if you have users on both of these unified communications platforms, who need to talk to each other.

The challenge when two independent phone systems are merged is replicating the extensions and dial plans of the two systems. This could get out of hand when dealing with a growing organization.

Configuring Single Number Reach (SNR) on both CUCM and Microsoft Teams in this scenario is an apt solution. It facilitates calls landing on a mobile number to ring simultaneously on a Cisco extension or a phone connected to Microsoft Teams and vice versa.

Thus eliminating the need to replicate dial plans or extensions of one system into another.

Here are two ways of integrating Microsoft Teams with CUCM.

Integrating Cisco call manager with Microsoft Teams using a SIP gateway

Requirements:

  • CUCM
  • Microsoft Teams
  • PSTN Gateway
  • SIP Gateway

How It Works:

In this scenario, a SIP gateway connects the Teams environment to the CUCM. The CUCM is also connected to a PSTN gateway to route calls to and from the outside world.

Once call routing is configured on both CUCM and Teams, users from both environments can communicate with each other.

Users on both systems can also use the PSTN gateway to reach/ talk to DID’s outside the CUCM / Teams environment. Here the external call handling is controlled by the Call Manager.

                Cisco Call Manager integration with Microsoft Teams using a SIP gateway

Direct Routing to integrate CUCM and Microsoft Teams

You can connect Microsoft Teams to Cisco Call Manager using a Session Border Controller (SBC) that is supported by Microsoft. The SBC could be a Cisco Unified Border Element (CUBE) or any compatible hardware from other manufacturers.

In the Microsoft world, this is called direct routing.

Cisco Jabber and Microsoft Teams calling integration

A detailed configuration is available beyond the scope of this article here.

3 – Cisco Jabber federation with Microsoft Teams

Cisco Jabber is a flexible communications client that can operate in phone only, IM only, or in a complete UC mode.

In team messaging mode, Cisco Jabber registers with the Webex Control Hub.

It provides Webex features like persistent one-to-one chats, team spaces, presence status, advanced file sharing, and more. The team messaging mode can be enabled for both on-premises users as well as cloud-based users.

In case there’s a phone system already present, there’s no need to change it in order for Jabber to work in team messaging mode.

Jabber users using team messaging mode can leverage CUCM for calling and voicemail.

Jabber users in this mode will have access to an extended set of features including:

  • List of members who can be toggled on/off
  • Capability to search for files, contacts, and messages
  • Create personal contact lists
  • Time and activity-based presence

Enabling the Jabber Team Messaging Mode:

  • Browse to the Webex Control Hub
  • Log in as an administrator
  • On the left panel, click on the Services tab and then on the Settings link on the Message card
  • Scroll down to the bottom of the page, and toggle the switch next to  “Enable Jabber team messaging mode”

To enable Jabber Team Messaging Mode for users:

  • On the left panel, click on the Users tab
  • Under the messages panel, toggle the switch next to  “Enable Jabber messaging mode”
  • Click on Save

Once Jabber is in team messaging mode, federation with Microsoft Teams is simple.

All you need to do is install a universal channel in Jabber or Webex.

Universal channels

Universal channels work like shared channels. They allow people outside your organization to chat with you, whether you use Jabber or Microsoft Teams.

It gives you the ease of staying in one messaging tool and makes intercompany collaboration effortless.

Universal channels are useful if you use Jabber in team messaging mode and have customers using Microsoft Teams, or vice versa.

You can invite your customers to your universal channel, and not have to worry about complicated integrations.

Once you’ve installed the Mio app, you benefit from Cisco Jabber and Microsoft Teams interoperability.

When your universal channel is installed, you can also break out and direct message anyone within that channel.

To connect Cisco Jabber and Microsoft Teams, install the Mio app here.
